Product Description
OXE 225HP-300HP Spare Parts Package
If your mission takes you over the horizon—long-term on station, deep in austere environments, and far from the flagpole—this heavy-duty remote location spare parts package is engineered for you. It includes everything you need for full operational resilience, no matter the scenario.
This kit features critical components like the upper and lower turbo assemblies, intercooler, and axle in/out assemblies—ensuring powertrain reliability even in the harshest conditions. Whether you're a military operator, a commercial fleet manager, or an adventurous off-grid explorer, this is the go-to solution for sustained performance and peace of mind when support is out of reach.
| No. | Description (OXE 250-300 Spare Parts) | UOM | Qty | Unit Price | Total Price | ||||||
| SP30-3114-467D | Upper turbo assembly | Pieces | 1 | $2,776.75 | $2,776.75 | ||||||
| SP30-3114-468F | Lower turbo assembly | Pieces | 1 | $4,002.00 | $4,002.00 | ||||||
| 30-3114-442C | Intercooler | Pieces | 1 | $1,505.10 | $1,505.10 | ||||||
| SP30-3112-002A | Axle in assembly | Pieces | 1 | $2,150.35 | $2,150.35 | ||||||
| SP30-3112-005A | Axle out assembly | Pieces | 1 | $890.30 | $890.30 | ||||||
| 30-3114-770 | Centaflex CF-R 106 CPL | Pieces | 2 | $452.40 | $904.80 | ||||||
| 30-0116-702B | Control head Dual CAN-bus | Pieces | 1 | $2,375.10 | $2,375.10 | ||||||
| 30-3160-040B | OXE Lower belt pre-tension tool kit | Pieces | 1 | $2,633.20 | $2,633.20 | ||||||
| 30-0160-122 | OXE300 - Diagnostic tool | Pieces | 1 | $478.50 | $478.50 | ||||||
| 30-0114-444 | Pump, E. fuel pump (sell 30-0190-935 kit form) | Pieces | 2 | $321.90 | $643.80 | ||||||
| SP30-3115-002A | Valve block assembly | Pieces | 1 | $1312.25 | $1,312.25 | ||||||
| 30-0116-909 | Water In Fuel Sensor (WIF) | Pieces | 2 | $478.50 | $957.00 | ||||||
| 30-0116-052 | Hydraulic pressure sensor 4000kPa | Pieces | 2 | $205.90 | $411.80 | ||||||
| 30-0113-052D | Transom anode, Zink | Pieces | 4 | $44.95 | $179.80 | ||||||
| SP-3114-158 | Voltage regulator | Pieces | 1 | $226.20 | $226.20 | ||||||
| SP-3114-129 | Set oil-filter element | Pieces | 4 | $34.80 | $139.20 | ||||||
| SP-3114-141 | Starter | Pieces | 1 | $754.00 | $754.00 | ||||||
| SP-3114-112 | Pressure sensor | Pieces | 1 | $120.35 | $120.35 | ||||||
| SP-3114-087 | Exhaust pressure sensor | Pieces | 1 | $114.55 | $114.55 | ||||||
| SP-3114-137 | Thermostat housing gasket | Pieces | 1 | $21.75 | $21.75 | ||||||
| 30-3114-887F | SW pump, Single impeller, OXE300 | Pieces | 1 | $716.30 | $716.30 | ||||||
| SP-3114-134 | Coolant pump with support | Pieces | 1 | $468.35 | $468.35 | ||||||
| 30-3190-913 | Impeller kit, Long, OXE300 | Pieces | 2 | $113.10 | $226.20 | ||||||
| SP-3114-061 | Temperature sensor | Pieces | 1 | $116.00 | $116.00 | ||||||
| 30-3114-847 | Thermostat gasket | Pieces | 2 | $15.95 | $31.90 | ||||||
| SP-3114-117 | Profile-gasket | Pieces | 1 | $15.95 | $15.95 | ||||||
| 30-3114-846 | Thermostat | Pieces | 2 | $46.40 | $92.80 | ||||||
| SP-3114-118 | Gasket, throttle body | Pieces | 1 | $15.95 | $15.95 | ||||||
| 30-3114-495A | Gasket, Thermostat Housing | Pieces | 2 | $2.90 | $5.80 | ||||||
| SP-3114-076 | Intake air temperature sensor | Pieces | 1 | $114.55 | $114.55 | ||||||
| SP-3114-148 | Exhaust manifold, cyl head gasket | Pieces | 1 | $52.20 | $52.20 | ||||||
| SP-3114-169 | O-ring | Pieces | 2 | $8.70 | $17.40 | ||||||
| SP-3114-168 | O-ring | Pieces | 2 | $8.70 | $17.40 | ||||||
| SP-3114-148 | Exhaust manifold, cyl head gasket | Pieces | 1 | $52.20 | $52.20 | ||||||
| SP-3114-152 | Flange nut | Pieces | 1 | $5.80 | $5.80 | ||||||
| SP-3114-080 | Gasket, manifold,turbo | Pieces | 2 | $40.60 | $81.20 | ||||||
| SP-3114-160 | Oil pressure sensor | Pieces | 2 | $69.60 | $139.20 | ||||||
| SP-3114-012 | Gasket | Pieces | 2 | $14.50 | $29.00 | ||||||
| SP-3114-113 | Oil pressure switch | Pieces | 1 | $36.25 | $36.25 | ||||||
| SP-3114-001 | Glow element | Pieces | 2 | $72.50 | $145.00 | ||||||
| SP-3114-092 | Alternator | Pieces | 1 | $1257.15 | $1,257.15 | ||||||
| 30-3190-901C | OXE300 Service Kit 50H | Pieces | 2 | $130.50 | $261.00 | ||||||
| 30-3190-902C | OXE300 Service Kit 200H 25" | Pieces | 6 | $552.45 | $3,314.70 | ||||||
| 30-3190-903E | OXE300 Service Kit 800H 25" | Pieces | 2 | $1,916.90 | $3,833.80 | ||||||
